Redmax EBZ8560RH Backpack Leaf Blower

$599.00

Experience unmatched power and efficiency with the Redmax EBZ8560RH Backpack Leaf Blower, the ultimate solution for fast and efficient leaf clearance.

  • High-powered 75.6cc engine for optimal performance

  • Lightweight design with padded straps for comfort

  • Variable speed control and extra-large fuel tank for extended use

Revolutionize your yard maintenance with the Redmax EBZ8560RH, making lawn care not just a task, but an enjoyable experience.

Experience unmatched power and efficiency with the Redmax EBZ8560RH Backpack Leaf Blower, the ultimate solution for fast and efficient leaf clearance.

  • High-powered 75.6cc engine for optimal performance

  • Lightweight design with padded straps for comfort

  • Variable speed control and extra-large fuel tank for extended use

Revolutionize your yard maintenance with the Redmax EBZ8560RH, making lawn care not just a task, but an enjoyable experience.

RedMax EBZ8560RH Backpack Leaf Blower

    • Model: EBZ8560-RH

    • Type: Frame-mounted commercial backpack blower (right-hand throttle variant)

    • Use: Heavy-duty leaf, clipping, and debris clearing on large properties, commercial sites, and municipal jobs

    • Key positioning: Identical power and output to EBZ8560 with tube-mounted right-hand throttle for operators who prefer precise in-hand throttle control

    • Type: 2-stroke, air-cooled

    • Cylinder displacement: 75.6 cm³ (4.6 cu in)

    • Output shaft power: 4.59 hp

    • Maximum power speed: 7,450 rpm

    • Idling speed: 2,000 rpm

    • Spark plug: NGK CMR7H (electrode gap 0.03 in)

    • Fuel tank volume: 77.77 fl oz (US)

    • Fuel consumption: 464 g/kWh

    • Air flow in pipe: 1,000 cfm

    • Air flow in housing: 1,200 cfm

    • Air speed (round nozzle): 220 mph

    • Blowing force: 47 N

    • Identical power and output to EBZ8560 standard; engineered for rapid clearing of wet leaves, heavy debris, and clippings

    • Frame-mounted rigid backpack housing

    • Height: 21.69 in

    • Length: 14.09 in

    • Tube diameter: 3.386 in

    • Padded back panel and commercial-grade harness for all-day comfort

    • Tube-mounted right-hand throttle for precise in-hand control (key difference from EBZ8560)

    • Large easy-access fuel cap for quick refueling

    • Easy-access air filter and spark plug for field service

    • Commercial-grade padded straps and hip belt

    • Included: Standard blower tube, round nozzle

    • Available separately: High-velocity nozzle, tube extensions, curved nozzle, OEM filters, spark plug, and service kits

    • Sound power level guaranteed (LWA): 115 dB(A)

    • Sound power level measured: 113 dB(A)

    • Sound pressure level at operator's ear: 106 dB(A)

    • Meets current EPA/CARB emissions and noise standards

    • Daily: Check fuel mix, inspect air filter, verify tube/clamps, visual check for leaks

    • Every 10 hours: Clean or replace air filter

    • Every 50 hours: Clean spark arrestor screen; inspect spark plug and fuel filter

    • Annual/seasonal: Replace spark plug and fuel filter; clean cooling fins and exhaust port; use 50:1 mix with quality 2-stroke oil

    • Height: 21.69 in

    • Length: 14.09 in

    • Tube diameter: 3.386 in

    • Dry weight: 25.4 lbs

    • Refer to the RedMax owner's manual and official RedMax warranty documentation for full coverage terms, conditions, exclusions, and claim procedures applicable to this model

    • Article number: 970 49 94-01 (Right-hand throttle "MKIII", NA)

    • RH = tube-mounted right-hand throttle vs. EBZ8560's left-hand frame-mounted throttle; all engine/performance specs are identical

    • Operators manual covers both EBZ8560 and EBZ8560-RH
